Hardware features

Remote Site Gateway Console Serial Console USB Network Flash Modem (V.92) Wireless Cellular Environmental Sensors RJ Pinout Power
ACM7004-2 4 4 2 4GB – – DI/O8 X2 Ext AC/DC
ACM7004-2-M 4 4 2 4GB Internal – DI/O8 X2 Ext AC/DC
ACM7008-2 8 4 2 4GB – – DI/O8 X2 Ext AC/DC
ACM7008-2-M 8 4 24 4GB Internal – DI/O8 X2 Ext AC/DC
ACM7004-5 4 4 55 4GB – – DI/O8 X2 Ext AC/DC
Resilience Gateway Console Serial Console USB Network Flash Modem (V.92) Wireless Cellular Environmental Sensors RJ Pinout Power
ACM7004-5-L 4 4 55 4GB – Global 4G LTE-A Pro DI/O8 X2 Ext AC/DC
ACM7004-2-L 4 4 2 4GB – Global 4G LTE-A Pro DI/O8 X2 Ext AC/DC
ACM7008-2-L 8 4 2 4GB – Global 4G LTE-A Pro DI/O8 X2 Ext AC/DC
ACM7004-5-LMA/LMV/LMP/LMR/LMCR/LMCT 4 4 55 4GB – 4G Multi-carrier DI/O8 X2 Ext AC/DC
ACM7004-2-LMA/LMV/LMP/LMR 4 4 2 4GB – 4G Multi-carrier DI/O8 X2 Ext AC/DC
ACM7008-2-LMA/LMV/LMP/LMR 8 4 2 4GB – 4G Multi-carrier DI/O8 X2 Ext AC/DC
Console Manager CM7100 Console Serial Console USB Network Flash Modem (V.92) Wireless Cellular Environmental Sensors RJ Pinout Power
CM7116-2-DAC1 16  2 2 4GB – – EMD5000 X2 Dual AC
CM7116-2-SAC1 16  2 2 4GB – – EMD5000 X2 Single AC
CM7132-2-DAC1 32  2 2 4GB – – EMD5000 X2 Dual AC
CM7148-2-DAC1 48  2 2 4GB – – EMD5000 X2 Dual AC
CM7148-2-SAC1 48  2 2 4GB – – EMD5000 X2 Single AC
CM7196A-2-DAC1 96  2 24 68GB – – EMD5000 X2 Dual AC
Infrastructure Manager IM7200 Console Serial Console USB Network Flash Modem (V.92) Wireless Cellular Environmental Sensors RJ Pinout Power
IM7208-2-DAC/DC 8  2 24 16GB Internal 4G Multi-carrier opt. EMD5000 Software Selectable3 Dual AC/DC
IM7216-2-DAC/DC 16  2 24 16GB Internal 4G Multi-carrier opt. EMD5000 Software Selectable3 Dual AC/DC
IM7232-2-DAC/DC 32  2 24 16GB Internal 4G Multi-carrier opt. EMD5000 Software Selectable3 Dual AC/DC
IM7248-2-DAC/DC 48  2 24 16GB Internal 4G Multi-carrier opt. EMD5000 XSoftware Selectable3 Dual AC/DC
IM7216-2-24U-DAC/DC 16 26 24 16GB Internal 4G Multi-carrier opt. EMD5000 Software Selectable3 Dual AC/DC
IM7216-2-24E-DAC/DC 16  2 267 16GB Internal 4G Multi-carrier opt. EMD5000 Software Selectable3 Dual AC/DC
1 All CM7100 have 2 x 10/100/1000 Ethernet ports except the CM7196A has dual 10/100/1000 Ethernet/SFP Fiber ports.
3 IM7200 pinouts are software-selectable between X1 & X2 on a port-by-port basis.
4 Dual Gigabit Ethernet/SFP Fiber Ports.
5 Single Gigabit Ethernet/SFP Fiber Port.
6 Built in 4 Port Gigabit Network Switch
7 Built in 24 Port Gigabit Network Switch with 2x Redundant Gigabit Fiber/Ethernet Ports
8 Internal temperature sensor

The serial pinout X1 is Cisco Rolled and X2 is Cisco Straight

Cellular Compatibility

Resilience Gateway ACM7000-L Cellular Modem LTE UMTS/HSDPA HSUPA/HSPA CDMA GSM EGSM DCS PCS
ACM700x-x-L Sierra EM7565 B1 (2100)
B2 (1900)
B3 (1800)
B4 (AWS)
B7 (2600)
B8 (900)
B9 (1800)
B12 (700ac)
B13 (700c)
B18 (800lower)
B19 (800 upper)
B20 (800DD)
B5 (850)
B26 (US 850 Ext)
B28 (700 APAC)
B29 (US 700de Lower)
B41 (TDD 2500)
B30 (2300 WCS)
B66 (AWS-3)
B32 (1500)
B46 (TDD 5200)		 B1 (2100)
B2 (1900)
B19 (800)
B8 (900)
B4 (AWS)
B5 (850)
B6 (800)
B9 (1700)
ACM700x-x-LMR Sierra MC7304 B1 (2100)
B3 (1800)
B7 (2600)
B8 (900)
B20 (800DD)		 B1 (2100)
B2 (1900)
B19 (800)
B26 (850)
B8 (900)		 B5 (850) B8 (900) B3 (1800) B2 (1900)
ACM700x-x-LMP Sierra MC7430 B1 (2100)
B3 (1800)
B7 (2600)
B8 (900)
B18 (800 lower)
B19 (800 upper)
B21 (1500 upper)
B5 (850)
B38 (TDD 2600)
B40 (TDD 2300)
B28 (700 APAC)
B39 (TDD 1900)
B41 (TDD 2500)		 B1 (2100)
B19 (800)
B8 (900)
B5 (850)
B6 (800)
B9 (1700)
TD-SCDMA
1880 – 1920 MHz
ACM700x-x-LMA
ACM700x-x-LMV
ACM700x-x-LMCR
ACM700x-x-LMCT		 Sierra MC7354 B2 (1900)
B4 (AWS)
B13 (700c)
B17 (700bc)
B5 (850)
B25 (1900)		 B1 (2100)
B2 (1900)
B26 (850)
B8 (900)
B4 (AWS)		 B5 (850)
B8 (900)
B3 (1800)
B2 (1900)
Infrastructure Manager IM7200 Cellular Modem LTE UMTS/HSDPA HSUPA/HSPA CDMA GSM EGSM DCS PCS
IM72xx-2-LR Sierra MC7304 B1 (2100)
B3 (1800)
B7 (2600)
B8 (900)
B20 (800DD)		 B1 (2100)
B2 (1900)
B19 (800)
B26 (850)
B8 (900)		 B5 (850) B8 (900) B3 (1800) B2 (1900)
IM72xx-2-LMP Sierra MC7430 B1 (2100)
B3 (1800)
B7 (2600)
B8 (900)
B18 (800 lower)
B19 (800 upper)
B21 (1500 upper)
B5 (850)
B38 (TDD 2600)
B40 (TDD 2300)
B28 (700 APAC)
B39 (TDD 1900)
B41 (TDD 2500)		 B1 (2100)
B19 (800)
B8 (900)
B5 (850)
B6 (800)
B9 (1700)
TD-SCDMA
1880 – 1920 MHz
IM72xx-2-LMA
IM72xx-2-LMV
IM72xx-2-LMCB
IM72xx-2-LMCR
IM72xx-2-LMCT		 Sierra MC7354 B2 (1900)
B4 (AWS)
B13 (700c)
B17 (700bc)
B5 (850)
B25 (1900)		 B1 (2100)
B2 (1900)
B26 (850)
B8 (900)
B4 (AWS)		 B5 (850)
B8 (900)
B3 (1800)
B2 (1900)
